Geo Lite™ Transit F-5030

GEOLOGICAL TRANSIT COMPASS

Compact aluminum geological transit combining direct-read azimuth measurement with a hinge clinometer for strike and dip field readings.

ModelGeo Lite™ Transit F-5030

Body ConstructionCompact aluminum body (approx. 30% smaller than full-size transit)

Configuration, availability and delivery confirmed with your quotation.

01 / FIELD CAPABILITIES

Built for the task.

Compact lightweight aluminum body roughly 30% smaller than traditional pocket transits
High-precision azimuth accuracy of ±0.5° with 1° graduations on a 0–360° scale
Integrated vertical clinometer reads slope and dip to ±1° across ±90° range
User-friendly tool-free magnetic declination adjustment with ±180° range
Induction damped needle stabilizes quickly for fast and repeatable field readings
Dual bubble vials (tubular and circular) ensure perfect level alignment
Reflective sighting mirror with center sighting hole for accurate bearing acquisition
Supplied with custom silicone protective cover for field impact resistance

02 / TECHNICAL DETAILS

Model: Geo Lite™ Transit F-5030
Body Construction: Compact aluminum body (approx. 30% smaller than full-size transit)
Azimuth Accuracy: ±0.5° with 1° graduations (0–360° azimuth scale)
Vertical Angle: ±1° with 1° graduations (±90° range)
Declination Adjustment: Tool-free magnetic declination adjustment ±180°
Needle Dampening: Induction damped needle on sapphire jewel suspension
Leveling Vials: Dual bubble vials (circular and tubular)
Sighting System: Precision mirror with sighting hole and sighting line
Protection: Silicone protective cover included
Mounting: Tripod mountable with 1/4-20 threading
